What is Film-Faced Plywood Used For?

Film-faced plywood is widely used in the construction industry, particularly in Australia, as a key component for concrete formwork applications. This type of plywood formwork is specifically designed with a smooth and waterproof film coating that prevents concrete from sticking to the surface, allowing for easy removal after the concrete has cured.

Key Uses of Film-Faced Plywood:

  • Foundation Work: It is commonly used to create accurate moulds for pouring concrete footings and slabs.
  • Wall Construction: Film-faced plywood is ideal for forming vertical concrete structures, ensuring a smooth finish on the walls.
  • Architectural Elements: This plywood is also utilised in producing high-quality concrete surfaces for exposed architectural features.

The waterproof film coating on film-faced plywood makes it highly resistant to moisture damage and wear. This durability allows construction teams to reuse the same panels multiple times, resulting in cost savings for large projects. Additionally, the smooth surface of the plywood eliminates the need for extensive finishing work on the concrete, saving both time and labour costs on site.

What is Formwork Plywood Used For?

Formply is an essential component in concrete construction projects throughout Australia. This specialised plywood is used to create temporary moulds that shape concrete into various structures such as foundations, walls, columns, and beams during the building process.

What are the Industry Standards for Formwork Plywood?

The industry standards for formwork applications are represented by F14 grade plywood and F17 grade plywood. These grades indicate the structural capacity and moisture resistance levels of the plywood:

  • F14 grade: Suitable for lighter formwork applications with moderate load requirements
  • F17 grade: Designed for heavy-duty formwork requiring maximum structural support

The Importance of Engineered Construction

The engineered construction of formply sheets allows them to handle repeated concrete pours without losing structural integrity. Construction teams rely on these panels to maintain precise dimensions and smooth finishes throughout multiple project cycles.

What is Moisture Resistance in Formply?

Moisture resistance is a critical feature of quality formwork plywood. The laminated construction and protective treatments prevent water absorption from wet concrete, which could cause warping or delamination. This durability ensures forms maintain their shape during the concrete curing process, delivering consistent results across residential and commercial construction projects.

Can You Use Normal Plywood for Formwork?

No, normal plywood is not suitable for concrete formwork applications. Standard plywood lacks the essential properties required to handle the demanding conditions of concrete construction.

Regular plywood fails in several critical areas:

  • Moisture vulnerability – absorbs water from wet concrete, causing warping and delamination
  • Insufficient pressure resistance – cannot withstand the weight and force of poured concrete
  • Poor surface quality – rough texture creates adhesion problems with concrete

Formply and concrete form plywood are engineered specifically for these challenges. These specialised materials feature:

  • Waterproof adhesives that prevent moisture penetration
  • Higher density construction for superior load-bearing capacity
  • Smooth, treated surfaces that release cleanly from cured concrete

Using standard plywood creates immediate problems. The material deforms under concrete pressure, sticks to the finished surface, and deteriorates rapidly. This leads to poor concrete finishes, increased labour costs, and frequent panel replacement.

Professional construction projects require the reliability that only purpose-built formwork materials can provide. The initial cost difference between normal plywood and formply becomes insignificant when considering the superior performance and reusability of proper formwork plywood.

Is Film Plywood Stronger Than Formwork Plywood?

Film-faced plywood, commonly known as concrete plywood, features a protective waterproof film coating that significantly enhances its durability and moisture resistance compared to standard formwork materials. This smooth surface treatment creates a barrier against water penetration and concrete adhesion.

Formply relies on its engineered wood construction for structural integrity but typically lacks the protective film layer found in film-faced variants. This absence makes traditional formwork plywood more susceptible to water damage and concrete sticking during repeated use cycles.

Both materials provide adequate structural strength for concrete construction applications. The key difference lies in environmental resistance and longevity:

  • Film-faced plywood: Superior moisture protection and easier concrete release
  • Standard formply: Strong structural performance but limited water resistance
  • Reusability: Film-faced options maintain integrity through more pour cycles

Film-faced plywood demonstrates greater strength in terms of environmental durability rather than pure load-bearing capacity. The waterproof coating extends service life and reduces replacement frequency, making it the stronger choice for demanding construction environments where moisture exposure is constant.

Should I get Film-Faced Plywood or Formply?

Film-faced plywood delivers superior concrete release properties through its waterproof film coating, creating smooth finishes that require minimal post-pour treatment. The protective surface prevents concrete adhesion, reducing labour costs and extending panel lifespan.

Formply in Australia provides exceptional structural integrity for demanding construction projects. F14 and F17 grades offer reliable moisture resistance and dimensional stability, making them cost-effective for multiple concrete pours.

Your choice depends on project requirements:

  • High-finish concrete work: Film-faced plywood
  • Standard structural applications: Formply panels
  • Budget-conscious projects: Standard formwork plywood

Contact Covert Procurement for expert guidance on selecting the right plywood formwork solution for your Australian construction project. Their specialists help match material specifications to your specific concrete forming requirements.
