Structural Laminated Veneer (LVL)

• Covert Procurement BestForm is Structural Laminated
Veneer Lumber (LVL) specifically used in structural
concrete formwork applications.
• It is manufactured in a controlled process to meet the
requirements of AS/NZS 4357.
• BSI is a world leading accreditation body that provides
the Quality control to show that the LVL complies with the
Australian Standards.
• Our LVL’s are sourced from managed plantation forests
that have a chain of custody. They are certified by the
Forest Stewardship Council (FSC).

Sizes

1.8m, 2.4m, 3m, 3.6m, 4.2m, 4.6m, 5,4m, 6m, 4 x 2 Timber (95mm x 47mm), 4 x 3 Timber (95mm x 65mm), 6 x 4 Timber (150mm x 77mm), Also available in the following lengths:

Sizes

1.8m, 2.4m, 3m, 3.6m, 4.2m, 4.6m, 5,4m, 6m, 4 x 2 Timber (95mm x 47mm), 4 x 3 Timber (95mm x 65mm), 6 x 4 Timber (150mm x 77mm), Also available in the following lengths:

What is Formwork LVL?

Formwork LVL is manufactured by bonding multiple layers of thin wood veneers under heat and pressure. This process ensures a high-strength, reliable, and stable product, ideal for demanding structural applications. The veneers are oriented with their grains parallel to the length of the member, which enhances the strength and uniformity of the final product compared to traditional timber. Covert Procurement BestForm is a Structural Laminated Veneer Lumber (LVL) used in structural concrete formwork applications. It is manufactured in a controlled process to meet the requirements of AS/NZS 4357.0:2005.

Key Features and Benefits

  1. Strength and Stability: Our formwork timber offers superior strength and stability compared to conventional timber. It is less prone to warping, twisting, and shrinkage, providing consistent performance in various environmental conditions​.
  2. Lightweight and Easy Handling: Despite its strength, our formwork LVL is lightweight, making it easier to handle, transport, and install on-site. This attribute helps reduce labour costs and increases overall efficiency​.
  3. Long Lengths and Customisation: Formwork LVL can be manufactured in longer lengths than traditional sawn timber, up to 4.8 meters, allowing for continuous spans and reducing the need for joints. This flexibility supports innovative structural designs and improved load distribution​​.
  4. Environmental Sustainability: Our formwork LVL product is sourced from managed forests with a chain of custody certified by the Forest Stewardship Council (FSC). Our commitment to sustainability ensures that your construction projects adhere to corporate social governance practices​​.
  5. Product Identification and Moisture Resistance: Formwork LVL bearers and joists are used to create suspended slab decks on construction sites. They can be used on high-rise commercial buildings, world-class residential buildings, or industrial warehouse construction. Each LVL beam is painted for product identification and moisture resistance​.
  6. Lighter & Stronger than Timber Alternatives: Faster and easier to install than alternatives – enhances productivity and reduces formwork labour costs. Improves concrete finish – formwork timbers are straight and uniform​.
  7. Easy Length Identification on Site: The ends of our LVL formwork products are colour-coded by length. Dimensions of each LVL are consistent. Compliant with relevant stress grade. Excellent veneer quality​.

Specifications

Formwork LVL from Covert Procurement is available in various dimensions and specifications to suit your varied structural needs:

  • Standard Sizes: We provide LVL formwork in common industry sizes including 95 x 65 mm and 95 x 77 mm, with lengths ranging from 1 metre to 3.6 metres and 4.8 metres.
  • Moisture Protection: Our LVL formwork is painted bright orange for moisture protection and easy on-site identification. This feature helps maintain the product’s integrity during storage and handling​​.
  • Compliance and Certification: All our formwork LVL products comply with the Australian and New Zealand standard AS/NZS 4357.0:2005 for structural laminated veneer lumber. Our products are also certified by the British Standards Institution (BSI), a world-leading accreditation body that provides quality control. This ensures our LVL formwork meets Australian quality and performance standards​​.

Applications of Formwork LVL

Formwork LVL is versatile and can be used in a variety of construction applications:

  • Concrete Formwork: Its primary use is in concrete formwork systems, including bearers, joists, walers, and soldiers. The uniformity and stability of LVL provide a smooth and accurate concrete finish, which is crucial for high-quality construction projects​.
  • Scaffold Planks: Our LVL formwork products can be designed to be used as scaffold planks, offering a strong and lightweight solution for safe and reliable performance in scaffolding applications​​.
  • Edgeboards: LVL formwork products can also be manufactured for use as edgeboards in concrete formwork. The raised edges and moisture protection treatment ensure durability and ease of use on construction sites​.
  • Formwork Bearers and Joists: Our LVL formwork products can be used to create suspended slab decks. Joists are supported by formwork LVL bearers that run perpendicular to the LVL joists.

Handling and Storage

Proper handling and storage are essential to maintaining the quality and performance of formwork LVL:

  • Storage: Store LVL undercover in a well-ventilated area to protect it from moisture and environmental damage. It should be stacked flat and clear of the ground on at least three evenly spaced bearers to avoid warping and bending​.
  • Handling: Handle LVL with care to prevent damage. Re-seal any cut edges with acrylic paint to maintain moisture resistance and prolong the product’s lifespan​.

Why Choose Covert Procurement for Formwork LVL?

Covert Procurement is dedicated to providing top-quality building materials that meet the highest industry standards. Our formwork LVL products are sourced from reputable manufacturers and undergo rigorous quality control processes to ensure reliability and performance.

Technical Support and Resources

Our team offers comprehensive technical support and resources to assist with your formwork LVL needs at any stage. From detailed product brochures to span tables and compliance documentation, we provide all the information required to make informed decisions and achieve successful project outcomes​.

Formwork Laminated Veneer Lumber (LVL) from Covert Procurement is ideal for construction professionals seeking a strong, reliable, and sustainable building material. With its superior performance characteristics and wide range of applications, formwork LVL ensures that your construction projects are built to last. Explore our selection of formwork LVL products today and experience the Covert Procurement difference.

For more information and to place an order, visit our website or contact our expert team. Let Covert Procurement be your trusted partner in building excellence.

Frequently Asked Questions about Structural Laminated Veneer (LVL)

1. What is Formwork Laminated Veneer Lumber (LVL)?

Formwork Laminated Veneer Lumber (LVL) is a high-strength engineered wood product made by bonding together multiple thin wood veneers under heat and pressure. This process results in a strong, stable, and uniform material ideal for various structural applications, including concrete formwork, scaffolding planks, and edgeboards.

2. What are the benefits of using Formwork LVL over traditional timber?

Formwork LVL offers several advantages over traditional timber:

  • Superior Strength and Stability: It is less prone to warping, twisting, and shrinkage.
  • Lightweight and Easy Handling: Despite its strength, it is lightweight, making it easier to handle and install.
  • Long Lengths and Customization: It can be manufactured in longer lengths, reducing the need for joints.
  • Environmental Sustainability: Sourced from sustainably managed forests, it is available with FSC certification upon request​.​

3. What are the common applications of Formwork LVL?

Formwork LVL is versatile and used in various construction applications, including:

  • Concrete Formwork: Used as bearers, joists, walers, and soldiers for smooth and accurate concrete finishes.
  • Scaffold Planks: Strong and lightweight scaffold planks for safe and reliable performance.
  • Edgeboards: Designed for use in concrete formwork as edgeboards​.

4. How should Formwork LVL be handled and stored?

Proper handling and storage are essential to maintain the quality of Formwork LVL:

  • Storage: Store LVL undercover in a well-ventilated area, stacked flat and clear of the ground on evenly spaced bearers.
  • Handling: Handle with care to avoid damage and re-seal cut edges with acrylic paint to maintain moisture resistance.

5. What certifications and compliance standards does Formwork LVL meet?

Formwork LVL from Covert Procurement complies with the Australian and New Zealand standard AS/NZS 4357.0:2005 for structural laminated veneer lumber. It is also certified by the British Standards Institution (BSI) and available with Forest Stewardship Council® (FSC®) certification upon request. This ensures that the product meets stringent quality and performance standards​.

6. What is the lead time for receiving Formwork LVL from Covert Procurement?

The lead time to purchase a container of formwork LVL is around 20 to 30 days. Covert Procurement can accommodate any specific quantity required, whether it’s three packs in a container or 20 containers. We ensure that your stock will be secured and delivered within the required lead time, providing flexibility and reliability for your construction projects.

7. What does Forest Stewardship Council (FSC) certification mean for Formwork LVL?

Our formwork LVL products are FSC-certified by the Forest Stewardship Council. Sourcing timber from recognised and audited managed plantation forests is important because of the following reasons:

  • Zero Deforestation: Trees are harvested and managed responsibly, ensuring no net loss of forest over time. Forest areas are identified and maintained.
  • Fair Wages and Work Environment: Workers are provided with proper training, adequate safety protocols, and fair wages.
  • Biodiversity Protection: Plant and animal species are protected to maintain ecological balance.
  • Community Rights: Local communities are consulted, and their legal and cultural rights to land and forest resources are respected.

This certification ensures that the Formwork LVL used in your projects supports sustainable and ethical forestry practices​.

For more information, visit our Formwork Laminated Veneer Lumber page.
